PHILIPS GreenPerform Highbay G5 - BY698 G5

160 lm/W system efficacy
75,000 hours lifetime @Ta 35⁰
Glare control (Narrow Beam), uniform illuminance (Wide Beam
Works seamlessly with the Interact IoT software and platform
Cold room application support

PHILIPS GreenPerform Highbay G5 - BY698 G5

The GreenPerform Highbay G5 continues the GreenPerform family’s enviable reputation for reliable performance. Not only does it deliver leading system efficacy and extended long-term quality, but it also promises Unified Glare Rating (UGR) control with compact dimensions. GreenPerform Highbay G5 is also fully compatible with IoT software such as Interact, which is a scalable, future-proof control system. The family also has a series that supports cold room applications with 100% humidity and no condensation. All benefits than make this robust, optimized, and versatile family suitable for almost all industrial applications.

  • Excellent energy savings
  • Long-term quality and reliability
  • Visual comfort
  • Wide range of applications
  • Connected ready for cloud-based IoT software applications

Applications

  • Manufacturing
  • Warehouses
  • Logistic center
  • Exhibition hall

Order Information

1. Product Data _ Fixed

Types (BY698P G5 PSU) LED105 LED150 LED200 LED250 LED300
Lumen Output (typ.) 10500lm 15000lm 20000lm 25000lm 30000lm
System Power (typ.) 67W 95W 126W 157W 192W

2. Product Data _ DALI

Types (BY698P G5 PSD) LED105 LED150 LED200 LED250 LED300
Lumen Output (typ.) 10500lm 15000lm 20000lm 25000lm 30000lm
System Power (typ.) 72W 102W 134W 168W 205W

3. Product Data _ InterAct

Types (BY698P G5 Connected) LED105 (ETO) LED150 LED200 LED250 LED300
Lumen Output (typ.) 10500lm 15000lm 20000lm 25000lm 30000lm
System Power (typ.) 68W 98W 133W 166W 203W

4. Product Data _ Cold Room

Types (BY698P G5 PSU) LED105 LED150 LED200 LED250 LED300
Lumen Output (typ.) 10500lm 15000lm 20000lm 25000lm 30000lm
System Power (typ.) 67W 95W 126W 157W 192W
