PHILIPS GreenPerform Highbay Rectangular - BY570

PHILIPS GreenPerform Highbay Rectangular - BY570

PHILIPS GreenPerform Highbay Rectangular - BY5701

PHILIPS GreenPerform Highbay Rectangular - BY5702

PHILIPS GreenPerform Highbay Rectangular - BY5703

PHILIPS GreenPerform Highbay Rectangular - BY5704

PHILIPS GreenPerform Highbay Rectangular - BY5705

140 lm/W system efficacy

70,000 hours lifetime @Ta 35⁰C

Glare control (Near Beam), uniform illustration (Wide Beam) and maximal spacing (High-Rack Optic)

Works seamlessly with the Interact IoT software and platform

Compact and robust design

PHILIPS GreenPerform Highbay Rectangular - BY570

The GreenPerform Highbay Rectangular continues the GreenPerform family’s enviable reputation for reliable performance. It is the first IP65 LED rectangular highbay in GreenPerform family. Not only does it deliver Unified Glare Rating (UGR) control with its optimized optical design, but it also promises leading system efficiency, compact dimensions, and extended long-term quality. Optimized for almost all industrial applications, it is also fully compatible with IoT software such as the Interact scalable system.

  • Excellent energy savings
  • Long-term quality and reliability within the lifetime span of 70,000 hours
  • Great design flexibility and convenience thanks to optimized optics and multiple control options

Applications

  • Warehouses
  • Logistical centers & distribution centers
  • General manufacturing
  • Exhibition centers and others

Order Information

  • PSU: Fixed output
12NC Description Specification
911401592061 BY570P LED250/NW PSU WB GM 182W, 25000lm, 4000K, wide beam
911401594661 BY570P LED250/NW PSU NB GM 182W, 25000lm, 4000K, narrow beam
911401591961 BY570P LED250/CW PSU WB GM 182W, 25000lm, 6500K, wide beam
911401594561 BY570P LED250/CW PSU NB GM 182W, 25000lm, 6500K, narrow beam
911401591661 BY570P LED200/NW PSU WB GM 144W, 20000lm, 4000K, wide beam
911401594461 BY570P LED200/NW PSU NB GM 144W, 20000lm, 4000K, narrow beam
911401591561 BY570P LED200/CW PSU WB GM 144W, 20000lm, 6500K, wide beam
911401594361 BY570P LED200/CW PSU NB GM 144W, 20000lm, 6500K, narrow beam
911401591261 BY570P LED150/NW PSU WB GM 111W, 15000lm, 4000K, wide beam
911401594261 BY570P LED150/NW PSU NB GM 111W, 15000lm, 4000K, narrow beam
911401591161 BY570P LED150/CW PSU WB GM 111W, 15000lm, 6500K, wide beam
911401594161 BY570P LED150/CW PSU NB GM 111W, 15000lm, 6500K, narrow beam
911401590861 BY570P LED100/NW PSU WB GM 69W, 10000lm, 4000K, wide beam
911401594061 BY570P LED100/NW PSU NB GM 69W, 10000lm, 4000K, narrow beam
911401590761 BY570P LED100/CW PSU WB GM 69W, 10000lm, 6500K, wide beam
911401593961 BY570P LED100/CW PSU NB GM 69W, 10000lm, 6500K, narrow beam
  • PSD: DALI output
12NC Description Specification
911401592961 BY570P LED250/NW PSD WB GM 199W, 25000lm, 4000K, wide beam
911401595461 BY570P LED250/NW PSD NB GM 199W, 25000lm, 4000K, narrow beam
911401593761 BY570P LED250/CW PSD WB GM 199W, 25000lm, 6500K, wide beam
911401595361 BY570P LED250/CW PSD NB GM 199W, 25000lm, 6500K, narrow beam
911401592761 BY570P LED200/NW PSD WB GM 152W, 20000lm, 4000K, wide beam
911401595261 BY570P LED200/NW PSD NB GM 152W, 20000lm, 4000K, narrow beam
911401593561 BY570P LED200/CW PSD WB GM 152W, 20000lm, 6500K, wide beam
911401595161 BY570P LED200/CW PSD NB GM 152W, 20000lm, 6500K, narrow beam
911401592561 BY570P LED150/NW PSD WB GM 119W, 15000lm, 4000K, wide beam
911401595061 BY570P LED150/NW PSD NB GM 119W, 15000lm, 4000K, narrow beam
911401593361 BY570P LED150/CW PSD WB GM 119W, 15000lm, 6500K, wide beam
911401594961 BY570P LED150/CW PSD NB GM 119W, 15000lm, 6500K, narrow beam
911401592361 BY570P LED100/NW PSD WB GM 75W, 10000lm, 4000K, wide beam
911401594861 BY570P LED100/NW PSD NB GM 75W, 10000lm, 4000K, narrow beam
911401593161 BY570P LED100/CW PSD WB GM 75W, 10000lm, 6500K, wide beam
911401594761 BY570P LED100/CW PSD NB GM 75W, 10000lm, 6500K, narrow beam
  • HRO PSU & PSD
12NC Description Specification
911401592261 BY570P LED250/NW PSU HRO GM 182W, 25000lm, 4000K, Fixed output
911401592161 BY570P LED250/CW PSU HRO GM 182W, 25000lm, 6500K, Fixed output
911401591861 BY570P LED200/NW PSU HRO GM 144W, 20000lm, 4000K, Fixed output
911401591761 BY570P LED200/CW PSU HRO GM 144W, 20000lm, 6500K, Fixed output
911401591461 BY570P LED150/NW PSU HRO GM 111W, 15000lm, 4000K, Fixed output
911401591361 BY570P LED150/CW PSU HRO GM 111W, 15000lm, 6500K, Fixed output
911401591061 BY570P LED100/NW PSU HRO GM 69W, 10000lm, 4000K, Fixed output
911401590961 BY570P LED100/CW PSU HRO GM 69W, 10000lm, 6500K, Fixed output
911401593061 BY570P LED250/NW PSD HRO GM 199W, 25000lm, 4000K, DALI output
911401593861 BY570P LED250/CW PSD HRO GM 199W, 25000lm, 6500K, DALI output
911401592861 BY570P LED200/NW PSD HRO GM 152W, 20000lm, 4000K, DALI output
911401593661 BY570P LED200/CW PSD HRO GM 152W, 20000lm, 6500K, DALI output
911401592661 BY570P LED150/NW PSD HRO GM 119W, 15000lm, 4000K, DALI output
911401593461 BY570P LED150/CW PSD HRO GM 119W, 15000lm, 6500K, DALI output
911401592461 BY570P LED100/NW PSD HRO GM 75W, 10000lm, 4000K, DALI output
911401593261 BY570P LED100/CW PSD HRO GM 75W, 10000lm, 6500K, DALI output
  • InterAct Pro
12NC Description Specification
911401516281 BY570X LED100/CW Connected NB GM 71W, 10000lm, 6500K, narrow beam
911401515581 BY570X LED100/CW Connected WB GM 71W, 10000lm, 6500K, wide beam
911401516381 BY570X LED100/NW Connected NB GM 71W, 10000lm, 4000K, narrow beam
911401514981 BY570X LED100/NW Connected WB GM 71W, 10000lm, 4000K, wide beam
911401516481 BY570X LED150/CW Connected NB GM 114W, 15000lm, 6500K, narrow beam
911401515781 BY570X LED150/CW Connected WB GM 114W, 15000lm, 6500K, wide beam
911401516581 BY570X LED150/NW Connected NB GM 114W, 15000lm, 4000K, narrow beam
911401515181 BY570X LED150/NW Connected WB GM 114W, 15000lm, 4000K, wide beam
911401516681 BY570X LED200/CW Connected NB GM 147W, 20000lm, 6500K, narrow beam
911401515981 BY570X LED200/CW Connected WB GM 147W, 20000lm, 6500K, wide beam
911401519881 BY570X LED200/NW Connected NB GM 147W, 20000lm, 4000K, narrow beam
911401515381 BY570X LED200/NW Connected WB GM 147W, 20000lm, 4000K, wide beam
911401533081 BY570X LED250/CW Connected NB GM 190W, 25000lm, 6500K, narrow beam
911401532881 BY570X LED250/CW Connected WB GM 190W, 25000lm, 6500K, wide beam
911401533181 BY570X LED250/NW Connected NB GM 190W, 25000lm, 4000K, narrow beam
911401532681 BY570X LED250/NW Connected WB GM 190W, 25000lm, 4000K, wide beam
911401515681 BY570X LED100/CW Connected HRO GM 71W, 10000lm, 6500K
911401515081 BY570X LED100/NW Connected HRO GM 71W, 10000lm, 4000K
911401515881 BY570X LED150/CW Connected HRO GM 114W, 15000lm, 6500K
911401515281 BY570X LED150/NW Connected HRO GM 114W, 15000lm, 4000K
911401516081 BY570X LED200/CW Connected HRO GM 147W, 20000lm, 6500K
911401515481 BY570X LED200/NW Connected HRO GM 147W, 20000lm, 4000K
911401532981 BY570X LED250/CW Connected HRO GM 190W, 25000lm, 6500K
911401532781 BY570X LED250/NW Connected HRO GM 190W, 25000lm, 4000K
  • Accessories
12NC Description
911401501171 BY570Z Suspension accessory
911401501071 BY570Z Pipe accessory
911401500771 BY570Z Mounting Bracket-S
911401500871 BY570Z Mounting Bracket-M
911401500971 BY570Z Mounting Bracket-L
