Lengths options with 600/1200mm; width options with 30/60/90mm
CRI 80 with flicker-free
Dali and Interact system are available
SlimBalance G2 SP560P is a cost-effective linear suspension office offer with multiple lumen output and product sizes. With its sleek and elegant design, it helps create attractive and differentiated office spaces for customers. This family has 3 different widths: 30mm, 60mm, and 90mm. Its max diffuser length reaches 12m which provides no diffuser gap between 2 luminaires after installation and better visual comfort in the office. PSU, Dali, and Interact System are offered by this new generation for easy and flexible light control. By means of its quick connector, it is easier for on-site installation as well.
| 12NC | Description | Specification |
|---|---|---|
| 911401556081 | SP560P LED40/840 L120W9 CD PSD | 35W, 4374lm, 4000K, 1200x90mm, DALI output |
| 911401555981 | SP560P LED20/840 L60W9 CD PSD | 18W, 2083lm, 4000K, 600x90mm, DALI output |
| 911401555881 | SP560P LED40/840 L120W6 CD PSD | 35W, 4213lm, 4000K, 1200x60mm, DALI output |
| 911401555781 | SP560P LED20/840 L60W6 CD PSD | 18W, 2000lm, 4000K, 600X60mm, DALI output |
| 911401555481 | SP560P LED40/840 L120W9 SD PSD | 35W, 4374lm, 4000K, 1200x90mm, DALI output |
| 911401555381 | SP560P LED20/840 L60W9 SD PSD | 18W, 2083lm, 4000K, 600x90mm, DALI output |
| 911401555281 | SP560P LED40/840 L120W6 SD PSD | 35W, 4213lm, 4000K, 1200x60mm, DALI output |
| 911401555181 | SP560P LED20/840 L60W6 SD PSD | 18W, 2000lm, 4000K, 600X60mm, DALI output |
| 911401553681 | SP560P LED40/840 L120W9 CD PSU | 35W, 4374lm, 4000K, 1200x90mm, Fixed output |
| 911401553581 | SP560P LED25/840 L120W9 CD PSU | 20W, 2544lm, 4000K, 1200x90mm, Fixed output |
| 911401553481 | SP560P LED40/840 L120W6 CD PSU | 35W, 4213lm, 4000K, 1200x60mm, Fixed output |
| 911401553381 | SP560P LED25/840 L120W6 CD PSU | 20W, 2450lm, 4000K, 1200x60mm, Fixed output |
| 911401553281 | SP560P LED12/840 L120W3 CD PSU | 12W, 1237lm, 4000K, 1200x30mm, Fixed output |
| 911401553181 | SP560P LED40/840 L120W9 SD PSU | 35W, 4374lm, 4000K, 1200x90mm, Fixed output |
| 911401553081 | SP560P LED25/840 L120W9 SD PSU | 20W, 2544lm, 4000K, 1200x90mm, Fixed output |
| 911401552981 | SP560P LED40/840 L120W6 SD PSU | 35W, 4213lm, 4000K, 1200x60mm, Fixed output |
| 911401552881 | SP560P LED25/840 L120W6 SD PSU | 20W, 2450lm, 4000K, 1200x60mm, Fixed output |
| 911401552781 | SP560P LED12/840 L120W3 SD PSU | 12W, 1237lm, 4000K, 1200x30mm, Fixed output |
| 911401551681 | SP560P LED20/840 L60W9 CD PSU | 18W, 2083lm, 4000K, 600x90mm, Fixed output |
| 911401551581 | SP560P LED12/840 L60W9 CD PSU | 12W, 1354lm, 4000K, 600x90mm, Fixed output |
| 911401551481 | SP560P LED20/840 L60W6 CD PSU | 18W, 2000lm, 4000K, 600x60mm, Fixed output |
| 911401551381 | SP560P LED12/840 L60W6 CD PSU | 12W, 1300lm, 4000K, 600x60mm, Fixed output |
| 911401551281 | SP560P LED6/840 L60W3 CD PSU | 6.5W, 645lm, 4000K, 600x30mm, Fixed output |
| 911401551181 | SP560P LED20/840 L60W9 SD PSU | 18W, 2083lm, 4000K, 600x90mm, Fixed output |
| 911401551081 | SP560P LED12/840 L60W9 SD PSU | 12W, 1354lm, 4000K, 600x90mm, Fixed output |
| 911401550981 | SP560P LED20/840 L60W6 SD PSU | 18W, 2000lm, 4000K, 600x60mm, Fixed output |
| 911401550881 | SP560P LED12/840 L60W6 SD PSU | 12W, 1300lm, 4000K, 600x60mm, Fixed output |
| 911401550781 | SP560P LED6/840 L60W3 SD PSU | 6.5W, 645lm, 4000K, 600x30mm, Fixed output |
| 911401585481 | SP560 Cont. Diffuser W9 | |
| 911401585381 | SP560 Cont. Diffuser W6 | |
| 911401585281 | SP560 Cont. Diffuser W3 | |
| 911401585181 | SP560 End Cap W9 PSD | |
| 911401585081 | SP560 End Cap W6 PSD | |
| 911401584981 | SP560 End Cap W3 |
