Thickness as thin as 8.3mm
Different installation methods, (T-bar, plater ceiling, CPC and suspended).
CRI > 80, SDCM<4, Flicker-free
Lifetime L80 50,000hours
Replaceable driver with plug in
UGR16, UGR19 versions available
GreenPerform Panel is the slimmest Panel with the highest efficacy in the market. It offers two lumen options with four dimension types, 200X1200, 300X1200, 600x600,600x1200, and three mounting options, recessed, suspended, and plaster ceiling.
| 12NC | Description | Specification |
|---|---|---|
| 911401719542 | RC160V LED40S 840 W60L60 PCV | 36W, 4000lm, 4000K, 600x600mm |
| 911401719522 | RC160V LED40S 840 W30L120 PSU | 36W, 4000lm, 4000K, 300x1200mm |
| 911401719512 | RC160V LED40S 865 W60L60 PSU | 36W, 4000lm, 6500K, 600x600mm |
| 911401719502 | RC160V LED40S 840 W60L60 PSU | 36W, 4000lm, 4000K, 600x600mm |
| 911401719492 | RC160V LED30S 865 W60L60 PSU | 28W, 3000lm, 6500K, 600x600mm |
| 911401719482 | RC160V LED30S 840 W60L60 PSU | 28W, 3000lm, 4000K, 600x600mm |
| 911401719472 | RC160V LED20S 840 W20L120 PSU | 20W, 2000lm, 4000K, 200x1200mm |
| 911401720812 | RC160V LED40S 865 W60L60 PSD | 36W, 4000lm, 6500K, 600x600mm |
| 911401720802 | RC160V LED40S 840 W60L60 PSD | 36W, 4000lm, 4000K, 600x600mm |
| 911401726852 | RC160V LED29S 840 W30L120 PSU UGR16 | 28W, 2900lm, 4000K, 300x1200mm, UGR16 |
| 911401726842 | RC160V LED29S 840 W60L60 PSU UGR16 | 28W, 2900lm, 4000K, 600x600mm, UGR16 |
| 911401719552 | RC160V LED40S 840 W60L60 CPC | 36W, 4000lm, 4000K, 600x600mm |
| 911401719532 | RC160V LED60S 840 W60L120 PSU | 55W, 6000lm, 4000K, 600x1200mm |
| 911401726862 | RC160V LED40S 840 W60L60 PSU OC IP44 | |
| 911401726872 | RC160V LED20S 840 W20L120 PSU OC IP44 | |
| 911401726882 | RC160V LED40S 840 W30L120 PSU OC IP44 | |
| 911401726892 | RC160V LED60S 840 W60L120 PSU OC IP44 | |
| 911401728352 | RC160Z SMB-597x597 | |
| 911401728362 | RC160Z SMB-297x1197 | |
| 911401728642 | RC160X LED40S TW W60L60 PSD OC IP44 | |
| 911401728632 | RC160X LED40S TW W60L60 PSD |
| 12NC | Description |
|---|---|
| 911401571181 | RC160X LED40/840 W60L60 WIA |
| 911401571281 | RC160X LED40/840 W30L120 WIA |
| 911401571381 | RC160X LED40/840 W60L120 WIA |
| 911401572081 | RC160X LED40/840 W60L60 WIA OC |
| 911401572181 | RC160X LED40/840 W30L120 WIA OC |
| 911401572281 | RC160X LED40/840 W60L120 WIA OC |
| 12NC | Description | Specification |
|---|---|---|
| 911401726922 | SP160P LED40S 840 W60L60 PSU | 36W, 4000lm, 4000K, 600x600mm |
| 911401726932 | SP160P LED20S 840 W20L120 PSU | 20W, 2000lm, 4000K, 200x1200mm |
| 911401726952 | SP160P LED60S 840 W60L120 PSU | 55W, 6000lm, 4000K, 600x1200mm |
| 911401726962 | SP160P LED20S 840 W20L120 PSU CD | 20W, 2000lm, 4000K, 200x1200mm |
| 911401726942 | SP160P LED40S 840 W30L120 PSU | 36W, 4000lm, 4000K, 300x1200lm |
